FEATURES

•             Single fiber bi-directional data links symmetric 1.25Gbps application

•             1490nm continuous-mode DFB laser transmitter and 1310nm burst-mode APD-TIA receiver

•             Reset-less burst-mode receiver simply the system design

•             More than 24dB wide dynamic range

•             0 to 70°C operating case temperature for C-temp class, and -40 to 85°C operating case temperature for I-temp class,

•             Single 3.3V power supply

•             Digital diagnostic monitoring interface

•             Digital burst RSSI function to monitor the input optical power level

•             LVPECL compatible data input/output interface

•             LVTTL transmitter disable control

•             LVTTL transmitter laser fault alarm

•             LVTTL receiver loss of signal indication

•             Low EMI and excellent ESD protection

•             Class I laser safety standard IEC-60825 compliant

•             RoHS6 compliance

Application

. Gigabit Ethernet Passive Optical Networks (GEPON) 20Km 1:32 application or 10Km 1:64 application
